Table 12. Rear panel information
Description Supplemental information
Trigger inputs/outputs BNC (f), TTL/CMOS compatible
10 MHz Reference in
Connector
BNC, female
Input frequency 10 MHz ± 10 ppm, typical
Input level –15 to +20 dBm, typical
Input impedance 200 Ω, nom.
10 MHz Reference out
Connector
BNC, female
Output frequency 10 MHz ± 1 ppm, typical
Signal type Sine Wave, typical
Output level +10 dBm ± 4 dB into 50 Ω, typical
Output impedance 50 Ω, nominal
Harmonics < –40 dBc, typical
VGA Video output
Connector 15-pin mini D-Sub; Drives VGA compatible monitors
Test set IO
25-pin D-Sub connector, female, available for external test set control
Aux IO
25-pin D-Sub connector, male, analog and digital I/O
Handler IO
36-pin parallel I/O port; all input/output signals are default set to
negative logic; can be reset to positive logic via GPIB command
GPIB
Two ports: dedicated controller and dedicated talker/listener
24-pin D-sub (Type D-24), female; compatible with IEEE-488.
USB Port
1 port on front panel and 4 ports on rear panel.
LAN
10/100BaseT Ethernet, 8-pin configuration; auto selects between the
two data rates
Line power (single phase)
Frequency, voltage 50/60 Hz/400 Hz for 100-120 V, 50/60 Hz for 220-240 V, power supply
is auto switching
Maximum 350 Watts
Note: Option H08 and Option H11 specifications are not provided in this N5230A specifications document.
