13
Table 7: Test port input
Description
Specification Typicals
Options 140, 145, 146, 240, 245, 246 Options 140, 145, 146, 240, 245, 246
Test port noise floor
Total average (rms) noise power calculated as the mean value of a linear magnitude trace expressed in dBm.
10 Hz IF bandwidth
300 kHz to 10 MHz
< –103 dBm
10 to 500 MHz < –112 dBm < –116 dBm
500 MHz to 4 GHz < –112 dBm < –120 dBm
4 to 10.5 GHz < –112 dBm < –119 dBm
10.5 to 13.5 GHz < –107 dBm < –114 dBm
13.5 to 15 GHz < –107 dBm < –114 dBm
15 to 20 GHz < –106 dBm < –114 dBm
1 KHz IF bandwidth
300 kHz to 10 MHz
< –83 dBm
10 to 500 MHz < –92 dBm < –96 dBm
500 MHz to 4 GHz < –92 dBm < –100 dBm
4 to 10.5 GHz < –92 dBm < –99 dBm
10.5 to 13.5 GHz < –87 dBm < –94 dBm
13.5 to 15 GHz < –87 dBm < –94 dBm
15 to 20 GHz < –86 dBm < –94 dBm
Direct receiver access input noise floor (Options 145, 146, 245, 246)
Total average (rms) noise power calculated as the mean value of a linear magnitude trace expressed in dBm.
10 Hz IF bandwidth
300 kHz to 10 MHz
< –119 dBm
10 to 500 MHz < –128 dBm < –132 dBm
500 MHz to 4 GHz < –128 dBm < –136 dBm
4 to 10.5 GHz < –128 dBm < –135 dBm
10.5 to 13.5 GHz < –123 dBm < –130 dBm
13.5 to 15 GHz < –123 dBm < –130 dBm
15 to 20 GHz < –122 dBm < –130 dBm
1 KHz IF bandwidth
300 kHz to 10 MHz
< –99 dBm
10 to 500 MHz < –108 dBm < –112 dBm
500 MHz to 4 GHz < –108 dBm < –116 dBm
4 to 10.5 GHz < –108 dBm < –115 dBm
10.5 to 13.5 GHz < –103 dBm < –110 dBm
13.5 to 15 GHz < –103 dBm < –110 dBm
15 to 20 GHz < –102 dBm < –110 dBm
Description
Specification Typicals
Options 140, 145, 146, 240, 245, 246 Options 140, 145, 146, 240, 245, 246
Compression level (at +8 dBm except as noted)
Power
Compression Power Compression
300 kHz to 10 MHz +5 dBm 0.10 dB
10 to 50 MHz +8 dBm 0.35 dB
50 MHz to 1 GHz +8 dBm 0.35 dB
1 to 8 GHz +8 dBm 0.25 dB
8 to 12.5 GHz +8 dBm 0.30 dB
12.5 to 13.5 GHz +8 dBm 0.55 dB
13.5 to 20 GHz +8 dBm 0.55 dB
Test port compression at 0.1 dB
300 kHz to 10 MHz
+5 dBm
10 MHz to 1 GHz +9 dBm
1 to 12.5 GHz +10 dBm
12.5 to 13.5 GHz +9 dBm
13.5 to 20 GHz +9 dBm
