C h a p t e r 5 I n s t a l l i n g Mu l t i p l e S t u d i o C a r d C a r d s
5-6 Antex StudioCard Copyright © 1997
Step 4 Locate an available
PCI expansion slot
for each card and
remove its cover,
as is shown in the
figure at right.
Be sure to keep the
retaining screw as
you will need it
later.
The cards should
all be installed next
to each other.
Step 5 Gently insert each
Antex StudioCard
into an available
PCI expansion slot,
then press down to
set it firmly into the
expansion slot, as
is shown in the
figure at right.
