C o n f i g u r i n g C l o c k S o u r c e S e t t i n g s

C h a p t e r 5

Antex Electronics Corporation

Antex StudioCard 5-15

Step 7

Select Internal
as the Sample
Clock Source
for the slave.

Step 8

Select Word as
the Sample
Clock
Reference for
the slave.

Step 9

Set the Clock
Source Sample
Rate to the
sample rate of
the master.

The system is now configured for synchronous operation.
