A p p e n d i x A
A-4 Antex StudioCard Copyright © 1997
Analog Input Listed below are the input specifications for the Balanced Line,
Unbalanced Line, and the Digital Line.
Balanced Line Unbalanced Line Digital Line
Recording
Level
+4 dBu nom.
+ 24 dBu max.
-10 dBV nom.
+10 dBV max.
Input
Impedance
24 k ohms 12 k ohms
Pro Format AES/EBU
EIAJ CP-340
Type I/IE-958
110
Ω
Consumer
Format
S/PDIF
EIAJ CP-340
TYPE II/EC-
958
75
Ω
Connection 25-pin male D
connector, or
female XLR on
supplied
breakout
cable
25-pin male D
connector, or
female XLR on
supplied
breakout
cable
15-pin female D
connector, or
female XLR on
supplied
breakout
cable
