A p p e n d i x A
Antex Electronics Corporation Antex StudioCard A-5
Analog Output Listed below are the output specifications for the Balanced
Line, Unbalanced Line, and the Digital Line.
Balanced Line Unbalanced Line Digital Line
Drive Level +4 dBu nom.
+ 24 dBu max.
-10 dBV nom.
+10 dBV max.
Output
Impedance
100 ohms 50 ohms
Load
Impedance
600 ohms or
greater 600 ohms or
greater
Pro Format AES/EBU
EIAJ CP-340
Type I/IE-958
110
Ω
Consumer
Format
S/PDIF
EIAJ CP-340
TYPE II/EC-
958
75
Ω
Connection 25-pin male D
connector, or
female XLR on
supplied
breakout
cable
25-pin male D
connector, or
female XLR on
supplied
breakout
cable
15-pin female D
connector, or
female XLR on
supplied
breakout
cable
