9 Sample Clock
Reference
Word256 Word256 selector. When selected, the sample clock generator will assume that
the selected clock source has a frequency 256 times the desired sample rate.
See note.
10 Sample Rate Sample rate selector. Selects the sample rate of the incoming sample clock
signal. This parameter must be set for Word and Word256 references. In all
other cases, the application program such as Antex Demo set this parameter at
time of record or playback.
11 Digital Format
AESEBU/
Consumer AESEBU/Consumer selector. In AESEBU mode, signals on the digital I/O pins of
the DB15 connector will conform to the AES/EBU electrical standards and
professional data format. In Consumer mode, they conform to S/PDIF electrical
standards and consumer data format.
12 Time Code Burn
In Select Enables timecode burn in on video feedthrough and source of timecode data.
“In” burns in externally input timecode, “Out” burns in timecode generated by the
StudioCard. “Off” disable burn in.
13 Time Code
Generate Turns on and off the generation of timecode to whatever destination is selected
in the "Options/Destination" combobox.
14 Time code Out
Position Shows the current timecode position of item 13 (above). Editable under
Options sub-menu.
15 Time code
Options See Timecode Options on page 10.
16 Time Code MTC
Record Turns on and off the generation of Midi Timecode from the timecode source
17 Time code In
Position Shows the position of whatever input (source) is selected in the
"Options/Source" combobox.
Note: If the sample rate clock source is disrupted, the sample rate must be reset by selecting a
different clock source then re-selecting the desired clock source.
