Antex Electronics StudioCard AV Pro, StudioCard 2000, & SC-22 - Manual (Page 14)

C h a p t e r 1 I n s t a l l i n g Y o u r S t u d i o C a r d
1-8 Antex StudioCard Copyright © 1997
Severe damage will occur to the StudioCard if
connected to phantom power.
Step 1 Power off your computer (if you have not already done so) and
unplug the power cord from the electrical outlet.
Step 2 Remove the housing from your computer to expose the
motherboard.
Step 3 Write the serial number for your Antex StudioCard in the space
below.
Serial Number: ___________________________________
If you ever need technical support from Antex in the future, you
will need this number. The serial number is on the backside of
your Antex StudioCard. Serial numbers are preceded by “S/N”
and contain five digits.
Example serial number: “S/N 48008”
