Argus Technologies Ltd.
014-114-C0 Rev D WC
Printed in Canada. © 2008 Argus Technologies Ltd. ARGUS and INEX are registered trademarks of Argus Technologies Ltd. All Rights Reserved.
Page 41 of 43
11.4 Mechanical
Dimensions of INEX Interface Module
11.5 Mechanical Dimensions of INEX Inverter Shelf
RS-485 port
USB port
RS-232 port
BAT -
DC cathode
BAT +
DC anode
CN20/CN21:
Inter-parallel
connectors
CN8: CAN COM port
with controller module
JP2: Mode selector
UC3: AC neutral
UC5: AC line
UC4: AC ground
CN9: Power
connector to
controller
CN7: COM/SYNC port
with STS module
CN11: Inverter fail open
collector terminals
