6.3.2 Inverter System Parameter Settings
Parameter Specification
BaudRate: Baud rate of COM port Selectable at 1) 2400bps, 2) 4800bps and 3) 9600bps
RS422 Addr: RS422 address RS422 communication protocol
Keypad tones: activation or de-activation
of audio alarm Selectable at 1) Enable and 2) Disable
Time&Date: Time and Date displayed on
LCD Time: hh:mm:ss
Date: yyyy-mm-dd
Language English
Brightness: LCD brightness
From 00~63 for adjusting LCD display contrast
Default: Reset Default value Press “Enter” for resetting the default value and “ESC” cancel the setting
Reset to Default Value (refer to Appendix A)
Dry Connect: Dry contact setting Refer to Module Parameter Settings section: Dry Contact Setting
Bat Calib: battery voltage calibration xx.xxV
For regulating the battery voltage value of LCD display of controller after
operating for long period of time.
The adjustable range is from 20.01V to 69.99V
Table F–System parameter settings
6.4 Module Parameter Settings
Parameter Setting Option
Output volt:
Inverter output voltage For INV-4810EA/INV-4815EA, selectable at:
1) 208Vac 2) 220Vac 3) 230Vac 4) 240Vac
For INV-4810A/INV-4815A, selectable at:
1) 110Vac 2) 115Vac 3) 120Vac
Output Freq:
Inverter output frequency Selectable at 1) 50Hz and 2) 60Hz
OPV HL:
High loss of inverter output voltage For Output volt = 208V, adjustable between 220V and 240V
For Output volt = 220V, adjustable between 233V and 252V
For Output volt = 230V, adjustable between 244V and 264V
For Output volt = 240V, adjustable between 254V and 276V
For Output volt = 110V, adjustable between 117V and 127V
For Output volt = 115V, adjustable between 122V and 132V
For Output volt = 120V, adjustable between 127V and 138V
OPV LL:
Low loss of inverter output voltage For Output volt = 208V, adjustable between 1760V and 198V
For Output volt = 220V, adjustable between 176V and 209V
For Output volt = 230V, adjustable between 185V and 218V
For Output volt = 240V, adjustable between 193V and 228V
For Output volt = 110V, adjustable between 89V and 105V
For Output volt = 115V, adjustable between 93V and 110V
For Output volt = 120V, adjustable between 100V and 114V
IPV LVSD:
Cut-off voltage of inverter input Adjustable between 36V and 46V
Power Limited:
Inverter output power capacity Adjustable between 50% and 100%
Fan Speed:
Fan speed level of inverter module Selectable at 1) Normal and 2) Full
Inverter On/off:
Setting all/single inverter turn on or off
⊙
ON
○
OFF
I nv: X
↕
Serial No:
xxxxxxxxx
⊙
ON
○
OFF
Single
Enter
Table G–Inverter parameter settings
1. All ->On/Off
2. Single
Serial No:
xxxxxxxxxx
On
Off
