6.4.2 Alarm Settings
6.4.2.1 Clear Alarm History
In CLEAR menu, press Enter for clearing all the alarm history.
6.4.2.2 Dry Contact Alarm Configuration A
Settings
Module
►System
Æ
Baud Rate
RS422 Addr
Keypad tones
Time&Date
Language
Password
Brightness
Default
► Dry connect
Bat Calib
Æ
DryCont: X↕
Alarm Type:XXX
Alarm No: X
xxxxxxxxxxx
Æ
⊙
INV
○STS
○Cont
○Smr
Æ
Alarm Type: INV
Alarm No: 1↕
Inverter fault
1 2 2 3 4
1. From the SETTING menu, select SYSTEM.
2. Then select DRY CONNECT to choose number. Use PgUp
key and PgDn key to change
DRYCONT. Press Enter to make selection.
D r y C o n t : 1
A l a r m T y p e : I N V
A l a r m N O : 0 2
I N v o v e r l o a d
3. To determine ALARM TYPE, select which module alarm group to assign to the dry contact.
Press Enter to make selection.
4. To select the alarm fault mode of the alarm type, enter ALARM NO. Press Enter to make
selection.
5. Press ESC to exit menu.
6.4.2.3 Dry Contact Alarm Configuration B
The alarm mode is programmed as follows:
No. Static Transfer Switch No. Inverter
01 Inverter unavailable 01 Inverter fault
02 Main unavailable 02 Inverter over load
03 Output overload 03 Inverter fan fault
04 Output short circuit 04 Power limit
05 K1 relay open 05 DC input abnormal
06 STS SCR1 short 06 Inverter low volt off
07 STS SCR2 short
08 Inverter bypass mode No. Controller
09 Over temperature 01 DC input low
10 MBS position abnormal 02 Controller temperature high
11 STS fan lock 03 Controller EPROM fault
12 STS fault mode 04 DC input over
13 STS Eeprom fault 05 CAN bus off
Table K–Dry contact alarms
