Heading Value
Address Inverter module location
Serial No Serial number of the selected inverter module
OPV Output voltage of the selected inverter module in Volts (V)
OPI Output current of the selected inverter module in Ampere (A)
OPF Output frequency of the selected inverter module in Hertz (Hz)
OPP Power capacity of the selected inverter module in Volt-Amperes (VA)
IPV DC input voltage of the inverter system in Volts (V)
Power Used Load level in percentage (%)
Heatsink Inverter system temperature in Celsius (ºC)
Ambient Temp. Inverter ambient temperature in Celsius (ºC)
Run time Inverter running time in hour (H)
Power Limited Power limited in percentage (%)
HW Rev Hardware version of the selected inverter module
SW Rev Software version of the selected inverter module
Table B–LCD display of inverter status
Heading Value
Address STS module location
Serial No Serial number of installed STS module
OPV Output voltage of STS module
OPI No display
OPF Output frequency of STS module
OPP No display
Mains AC Vol Voltage of AC connected to STS module
Main AC Freq Frequency of AC connected to STS module
INV AC Volt Voltage of Inverter AC connected to STS module
INV AC Freq Frequency of Inverter AC connected to STS module
MBS Position Current MBS position (IBP /ISS/Normal/MSS/MBP)
Running Mode STS current running mode (Inverter/mains/standby/power on)
Default Volt STS default output voltage (V)
Default Freq STS default output frequency (Hz)
Power Used Load level in percentage (%)
Temperature STS temperature in Celsius (ºC)
Run Time STS running time in hour (H)
Priority Mode
Operation mode of STS module;
ON = output from inverter, OFF = output from AC
STS, the default is ON
HW Rev Hardware version of STS module
SW Rev Software version of STS module
Table C–LCD display of STS status
Heading Value
Hardware Version Hardware version of controller module
Firmware Version Software version of controller module
Input Voltage DC input voltage of controller module in Volts (V)
Temperature Controller temperature in Celsius (ºC)
Table D–LCD display of controller status
