Alpha Technologies FXM 650, 1100, 2000 UPS User Manual
Page 83
81
017-230-B4 Rev B
Table T — Electrical Specifications
Parameter
Value
Input
Voltage (nominal), Vac
120 or 230, optional 208, 210, 240 for FXM 2000, 120 only for FXM 650-48
Frequency, Hz, ±5%
60/50 (auto-detection), Output frequency = Input frequency
Current, Amps
(@ nominal Vin and max
battery charging current)
FXM 650-24: 8.7/4.5 @120/230 Vac
FXM 650-48: 10.5 @120 Vac
FXM 1100: 15.5/8 @120/230 Vac
FXM 2000: 20/12 @120/230 Vac
Input Circuit Breaker
Ratings, Amps
FXM 650-24: 15/10 @120/230 Vac
FXM 650-48: 15 @120 Vac
FXM 1100: 20/10 @120/230 Vac
FXM 2000: 25/15 @120/230 Vac
Battery Circuit Breaker
Ratings, Amps
FXM 650-48/1100: 50
FXM 650-24/2000: 80
Output
Voltage (nominal), Vac
120 or 230, optional 208, 210, 240 for FXM 2000, 120 only for FXM 650-48
Frequency, Hz, ±5%
60/50 (output frequency = input frequency.)
Power, W/VA
FXM 650: 650
FXM 1100: 1100
FXM 2000: 2000
Waveform
Pure sine wave
Load Crest Factor
3:1 (load dependent)
Output Voltage Distortion
< 3% THD (resistive load)
Efficiency
7
Normal Mode
Backup (Inverter) Mode
> 98%
> 82% (48 Vbatt), >75% (24 Vbatt)
Transfer Time, mS
AVR to Backup
Backup to AVR
5 (typical)
5 (typical)
Line Qualification Time
3 seconds (factory default), user adjustable in increments of 1 sec until 1 minute, and
then in increments of 1 minute to 15 minutes max.
Battery String Voltage
FXM 650 - 24: 24 Vdc
FXM 650 - 48/1100/2000: 48 Vdc
1. Capable of operating at 73% of rated full load for up to 2 hours at 74°C. Above 55°C ambient, derate output power by 1.4% per °C rise,
up to 74°C max.
2. Capable of operating at 100% of rated full load below 0°C down to -40°C after the Alpha FXM has been stabilized at 0°C for at least 1
hour.
3. FXM 1100/2000-120V only: above 50°C ambient, derate output power by 1.1% per °C rise, up to 74°C max.
4. Derate 2°C per 300 m (1000 ft) above 1400 m (4500 ft).
5. For FXM650/1100-48(Q), the default setting of C3 is “FAULT”.
6. The LCD display may not function below -15°C. It gradually resumes normal operation as the temperature rises above -15°C. This will not
affect the operation of the Alpha FXM.
Table S — Mechanical Specifications
Parameter
Value
User inputs Three optically-isolated and powered inputs are located on the front panel. When
they are shorted, their functions are:
S1: Starts the self test.
S2: Activates an alarm.
S3: Unit shutdown.
User interface
6
2 x 20 backlit alpha-numeric LCD screen. Three control buttons located below.
