017-230-B4 Rev B 62
HyperTerminal Menu Tree
Submenus #1 and 2 are read-only screens for monitoring the Alpha FXM. To control the Alpha FXM, use sub-
menus #3 and #4, the Maintenance submenus.
Figure 55 — Menu Tree
1-Unit Specifications
Unit Model
Input
Voltage
Frequency
Output
Voltage
VA
Battery Voltage
Voltage
Software Version
2-Input/Output Values
Input
Voltage
Frequency
Output
Voltage
Current
VA
Battery
Voltage
Temperature
3-Maintenance
30-Battery Test Options
300-Set Battery Test DoD
301-Battery Test On/Off
31-Inverter On/Off
310-Set Inverter-Off Delay
311-Inverter On/Off
32-Change Password
34-Line Qualify Time
1) Set to 3 seconds (default)
2) Set to 10 seconds
3) Set to 20 seconds
4) Set to 30 seconds
5) Set to 40 seconds
6) Set to 50 seconds
35-Low Battery Warning
Voltage
36-Load Shed Timer
On/Off
1) Timer 1 on
2) Timer 1 off
3) Timer 2 on
4) Timer 2 off
5) Timer 3 on
6) Timer 3 off
0-Main Menu
Submenus Submenus
Press Enter to go up 1 level in
the menu tree.
To reach any submenu, type
in its number and press Enter.
To reach the main menu, type
0 and press Enter.
These 2 read-only screens show the Alpha FXM’s
factory specifications or the present input and output
measurements. The Input/Output Values submenu
does not automatically update. For an updated value,
type
2 and press Enter.
