63 017-230-B4 Rev B
6.5.3 Line Status
Line status reports the line condition. For an updated value, press Enter.
Table E — Line Status (see Figure 54)
Normal The line is within specifications. See "Table V — Boost/Buck/Line Transfer Thresholds" on
page 82. The Alpha FXM is operating in Line mode.
Boost Line voltage is out of tolerance. The Alpha FXM is operating in Boost mode.
Buck Line voltage is out of tolerance. The Alpha FXM is operating in Buck mode.
Blackout The line is absent.
Freq low Line frequency is too low.
Freq high Line frequency is too high.
6.5.4 Output Status
Output status reports how the Alpha FXM is producing power. For an updated value, press Enter.
Table F — Output Status (see Figure 54)
Line mode
Battery mode
Battery mode, low bat warning
Battery mode (testing battery)
Battery bypass mode
Boost mode
Boost 2 mode
Buck mode
Hot swap mode
Inverter off due to fault
Inverter off due to low battery
Inverter off at start-up
Shutdown due to user request
NOTE:
When using the terminal interface, Battery mode and Battery bypass mode are the same as Inverter mode and
Inverter bypass mode when using other communications methods.
