Baud rate and protocol
PowerCage FOX boards
Control .............................. 9600 baud, 8 data bits, 1 stop bit, no parity
Pass-through ...................... 9600 to 115,200 baud
Serial control pin configurations
Captive screw connector .......... 1 = Tx, 2 = Rx, 3 = GND
Mini stereo jack ....................... RS-232: tip = Tx, ring = Rx, sleeve = GND
Program control ............................. Extron control/configuration program for Windows
Extron Simple Instruction Set (SIS)
General
Power consumption* ..................... 1 or 2* (positive-negative), 100 VAC to 240 VAC, 50-60 Hz; internal, hot-
swappable
* A redundant power supply is optional.
System ..................................... Enclosure without boards: 12.40 watts at 115 VAC, 60 Hz
Each FOX board at 115 VAC, 60 Hz
FOX 3G HD-SDI: 1.84 watts
Power input requirements (boards)
12 VDC, 1.0 A, supplied by the PowerCage enclosure
Temperature/humidity .................... Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
Cooling .......................................... Enclosure: fans, front to back
Boards: convection, within the PowerCage enclosure
Mounting — PowerCage enclosure
Rack mount ............................. Yes
Enclosure type ................................ Metal
Enclosure dimensions
PowerCage enclosure .............. 5.25" H x 17.0" W x 12.25" D (3U high, full rack wide)
13.3 cm H x 43.2 cm W x 31.2 cm D
(Depth excludes connectors on the optional boards. Width excludes rack ears.)
PowerCage FOX boards ........... Fits a double slot opening in a PowerCage enclosure.
Product weight
PowerCage enclosure .............. 11.6 lbs (5.3 kg)
PowerCage FOX boards ........... 1.1 lbs (0.5 kg)
Shipping weight
PowerCage enclosure .............. 13 lbs (6 kg)
PowerCage boards ................... 2 lbs (1 kg) each
Vibration ........................................ ISTA 1A in carton (International Safe Transit Association)
Regulatory compliance
Safety ...................................... CE, c-UL, FDA Class 1, UL
EMI/EMC ................................. CE, C-tick, FCC Class A, ICES, VCCI
MTBF ............................................. 30,000 hours
Warranty ........................................ 3 years parts and labor
NOTES: All nominal levels are at ±10%.
Specifications are subject to change without notice.
PowerCage Fox 3G HD-SDI • Reference Information 25
