Operation
After the transmitting and receiving units and all of their connected devices are powered
up, the system is fully operational. If any problems occur, verify that the cables are routed
and connected properly, and that all display devices have identical resolutions and refresh
rates. If problems persist, call the Extron S3 Sales & Technical Support Hotline. See the
contact numbers
on the rear cover of this guide for the Extron office nearest you.
To take advantage of the various adjustments and test patterns available on the
PowerCage FOX 2G AV, connect a computer or other RS-232 capable device to the
Remote/RS-232 port on either board or to the Config port on the PowerCage 1600 front
panel and operate the system using either
SIS commands
or the
FOX Extenders Control
Program
.
