Restore Last-Session’s settings — Loads the icons and icon captions that were
saved during the last session. If you saved the changes of the previous session to disk
the last time you exited the program, the ties from that session are also loaded.
Select Printer ... — Selects the target printer.
Print Tie Map — Prints the tie set that is displayed on the screen.
Exit — Closes the Extron Matrix Switchers Control Program.
Tools menu
Assign Device Icons — Displays the complete set of input and
output device icons. You can drag any of these icons to the input
and output boxes.
Edit Device Palette — Allows you to add your own device icon
graphics.
RGB Delay settings — Displays the RGB Delay/Mute/Output-
Volume Adjust window (see figure 35 ), which shows the RGB
delay setting for each output and allows you to change it. This
window also allows you to mute and unmute the video and audio
output and displays the output volume level and allows you to
change it.
Figure 35. RGB Delay/Mute/Output-Volume Adjust Window
Audio-Input-Gain settings — Displays the Configure Audio Options window (see
figure 36 ), which shows the audio gain level settings for each input and allows you to
change them.
Figure 36. Configure Audio Options Window
MVX 44 / 48 / 84 / 88 VGA Matrix Switchers • Remote Operation 53
