HSA 822M • Introduction
Introduction, cont’d
HSA 822M
2
Chapter Two
Installation
Installation Overview
Preparing the Routing Template
Preparing the Table
Cabling and Installing the AAPs
Routing the AAP Cables and Installing the Clamshell
Cabling the Enclosure
Bezels
1-4
The HSA 822M is available in a variety of surface finishes,
including black anodized aluminum, brushed aluminum,
brushed brass, and polished aluminum.
Features
• CSA listed
• Easy access to connectors and controls
• Durable motorized movement
• Motion-limiting safety features to prevent injury and
equipment damage
• A variety of available surface finishes
• A variety of colors of included RJ-45 connector bezels:
black, red, blue, orange, gray, white, ivory, yellow, and
green
• Compact size
• Easy installation of up to four powered or passive double
space Extron AAPs
The space behind the AAP panel is limited. The online
Connectivity Configurator, available at
www.extron.com , offers guidance as to the fit of AAPs
into this space.
• RJ-45 (CAT 5/6) network and data connections
(teminated in accordance with the TIA/EIA T 568 A
standard)
• Grounded AC plugs
