Dissolved oxygen MultiLab 4010-1
52 ba76141e03 03/2014
Calibration
evaluation
After the calibration, the meter automatically evaluates the current status of the
calibration. The evaluation appears on the display and in the calibration record.
ProOBOD
calibration
evaluation
Calibration record
(USB output)
Menu item Setting/
function Description
Calibration /
Calibration data stor-
age /Display - Displays the calibration records.
Further options:

Scroll through the calibration
records with <><>.
 Output the displayed calibra-
tion record to the interface with
/[USB output].
 Output all calibration records
to the interface with
[USB output].
 Quit the display with /
[Back] or
 Switch directly to the mea-
sured value display with .
Calibration /
Calibration data stor-
age / Output to
RS232/USB - Outputs the calibration data stor-
age to the interface
Display Calibration record Relative slope
+++ S = 0.94 ... 1.06
++ S = 0.92 ... 0.94 or
S = 1.06 ... 1.08
+ S = 0.90 ... 0.92 or
S = 1.08 ... 1.10
Error Error S < 0.90 or
S > 1.10
Error elimination (see section 14 W HAT TO DO IF ...,
page 88)
CALIBRATION Ox
03.04.2013 07:43:33
ProOBOD
Ser. no. 12B100016
ProOBOD Cap 12B100015
Relative slope 0.98
Sensor +++
