YSI 5200 - Manual (Page 17)

YSI Incorporated 15 5200 Recirculating System Monitor
3.4.2 Optional 6509 – Rail Mount Kit
The 5200 Monitor can be easily mounted to pipe or handrail (1 to 1½ inch diameter) using the optional
6509 Rail Mount Kit. When using the 6509 Rail Mount Kit, the 006515 mounting flanges will have to be
modified by drilling two holes to accept the u-bolts. The predrilled metal plates can be used as a template.
CAUTION: The monitor should not be mounted on electrical conduit, a hot or vibrating pipe or structure,
or near a high heat source, an AC motor, transformer, radio transmitter or antenna.
3.4.3 Optional 6505 – Weather shield
The Weather Shield provides wall or optional rail mounting capability for the 5200 Monitor.
CAUTION: The monitor should not be mounted on electrical conduit, a hot or vibrating pipe or structure,
or near a high heat source, an AC motor, transformer, radio transmitter or antenna.
