EV Charging Station User Manual & Installation Instructions
GE EV Charging Station User Manual 79 of 86
Depending on the choice of IP address range above for the configuration of the EVSEs in the
network, set the Ethernet IP address, Subnet Mask, and Default Gateway to the corresponding
settings:
IP Address 172.25.1.100
Subnet Mask 255.255.255.0
Default Gateway 172.25.1.1
or
IP Address 172.26.1.100
Subnet Mask 255.255.255.0
Default Gateway 172.26.1.1
Click on OK and close both windows to save your settings.
4.4.3 Install EV100 RFID Host Application Software.
After the controller configuration of all EVSE and the host PC’s TCP/IP setups have been completed,
the Host Application EV100 for RFID authentication needs to be installed.
GE strongly recommends using a clean PC with a fresh Windows XP or Windows 7 installation only,
to avoid any interference with other installed software.
In order to install EV100 application, make sure you have full Windows Administrator rights
The detailed installation steps are defined in the manual provided with the application on CD 1.
“EV100 – GE EV Charging Station Manager Application”.
For trouble shooting, please also refer to that manual.
1. Power up the network switch and keep it connected to the Host PC at all times during the SW
installation and subsequent operation.
Note: Reboot PC to finalize the configuration
Note: Make sure the Host PC is configured according to the same IP address settings as
entered in the EVSE configuration server page.
Note: Make sure the switch is always powered and connected to the Host PC. In case of
a direct connection from the EVSE to a Host PC without interposed Ethernet switch, the
EVSE needs to be powered each time the Host PC is powered up, or the listener service is
manually restarted.
Action
required !
