EV Charging Station User Manual & Installation Instructions
GE EV Charging Station User Manual 52 of 86
Technical Characteristics
SAE Compliant Level II per J1772
Vehicle Interface SAE J1772 EV connector
Cable Length 20’ cable
AC Max Charging Power Output** 7.2 kW (240VAC @ 30A)
Voltage and Current Rating
208-240VAC @ 30A
AC Power Input 208-240VAC requiring only Line 1, Line 2 and Earth ground
Short Circuit Rating 5kA @ 240 VAC
Recommended Service Panel
Breaker Pole, Wall, Single Pedestal: 2-pole 40A breaker on dedicated circuit
Double Pedestal: (Qty. 2) 2-pole 40A breaker on dedicated circuit
Ground Fault Protection Internal 20mA CCID with auto-re-closure, does not require a GFCI
in service panel
Cold Load Start Random start up between 0 and 15 minutes
Local Area Network CAT5 Ethernet
Network Communication Protocol TCP/IP
Network Security
GE recommends that network be VPN and Firewall protected
Metering Accuracy 2% accurate on voltage and current; 4% accurate on power and
energy
RFID Reader ISO15693 compliant
Display Screen Vacuum Fluorescent Display
Standby Power 5W typ.
Indoor Ventilation Signal provided to turn on facility fans
Outdoor Rated Enclosure NEMA 3R
Safety Compliance UL 2231, UL 2251, UL 2594, cUL 2231, cUL 2594, NEC 625, SAE
J1772
Surge Protection 6kV @ 3000A
EMI Compliance FCC Part 15 Class A
Operating Temperature -30  C to +50  C ambient
Operating Humidity Up to 95% non-condensing
Approximate Shipping Weights Single Pedestal: 120 lb
Single Pedestal: 160 lb
Pole: 75 lb
Wall: 75 lb
Dimensions Single Pedestal: 57.6”H x 18.4”W x 20.9”D
Double Pedestal: 57.6”H x 18.4”W x 28”D
Wall: 31.5”H x 14.9”W x 11.2”D
Pole: 31.5”H x 14.9”W x 11.2”D
- Table 10 -
**The maximum power consumption is determined by EVSE. The actual power consumption is
determined by EV.
