Data Sheet
August 24, 2010
QRW010/025/035/040 Series Power Modules; dc-dc Converters
36 Vdc - 75 Vdc Input, 1.0 to 12 Vdc Output; 10 A to 40 A
Document Name: DS03-113 ver.4.4
PDF name: QRW035_Series.pdf
World Wide Headquarters
Lineage Power Corporation
601 Shiloh Road, Plano, TX 75074, USA
+1-800-526-7819
(Outside U.S.A.: +1-972-244-9428)
www.lineagepower.com
e-mail: [email protected]
Asia-Pacific Headquarters
Tel: +65 6593 7211
Europe, Middle-East and Africa Headquarters
Tel: +49 89 878067-280
India Headquarters
Tel: +91 80 28411633
Lineage Power reserves the right to make changes to the product(s) or information contained herein without notice. No liability is assumed as a result of their use or
application. No rights under any patent accompany the sale of any such product(s) or information.
Lineage Power DC-DC products are protected under various patents. Information on these patents is available at
www.lineagepower.com/patents .
© 2009 Lineage Power Corporation, (Plano, Texas) All International Rights Reserved.
Table 2. Device Options
Characteristic Definition
Form Factor Q Q = Quarter Brick
Family Designator R Family Designator
Input Voltage W W = Wide Range, 36V-75V
Output Current 035A0 035A0 = 0 35.0 Amps Maximum Output Current
B B = 12V nominal
A A = 5.0V nominal
F F = 3.3V nominal
G G = 2.5V nominal
Y Y = 1.8V nominal
M M = 1.5V nominal
P P = 1.2V nominal
S S = 1.0V nominal
Omit = Default Pin Length shown in Mechanical Outline Figures
8 8 = Pin Length: 2.79 mm ± 0.25mm , (0.110 in. ± 0.010 in.)
7 7 = Case Pin (only available with H option)
6 6 = Pin Length: 3.68 mm ± 0.25mm , (0.145 in. ± 0.010 in.)
Omit = Latching Mode
4 4 = Auto-restart following shutdown (Overcurrent/Overvoltage)
Omit = Positive Logic
1 1 = Negative Logic
Omit = Standard open Frame Module
H H = Heat plate, for use with heat sinks or cold-walls
Customer Specific XY XY = Customer Specific Modified Code, Omit for Standard Code
Omit = RoHS 5/6, Lead Based Solder Used
Z Z = RoHS 6/6 Compliant, Lead free
Output Voltage
Ra
ti
n
g
s
Character and Position
Op
ti
o
n
s
Pin Length
Action following
Protective Shutdown
On/Off Logic
Mechanical Features
RoHS
