QRW010/025/035/040 Series Power Modules; dc-dc Converters
36 Vdc - 75 Vdc Input, 1.0 to 12 Vdc Output; 10 A to 40 A
* ISO is a registered trademark of the International Organization of Standards
** UL is a registered trademark of Underwriters Laboratories, Inc.
†
CSA is a registered trademark of Canadian Standards Association.
‡ VDE is a trademark of Verband Deutscher Elektrotechniker e.V.
§ This product is intended for integration into end-use equipment. All of the required procedures of end-use equipment
should be followed.
Document Name: DS03-113 ver.4.4
PDF name: QRW035_Series.pdf
Features
 Compliant to RoHS EU Directive 2002/95/EC (-Z
versions)
 Compliant to ROHS EU Directive 2002/95/EC with
lead solder exemption (non-Z versions)
 Delivers up to 40A output current
 Ultra High efficiency – 91% at 3.3V full load
 Industry standard DOSA Compliant Quarter brick:
57.9 mm x 36.8 mm x 9.5 mm
(2.28 in x 1.45 in x 0.375 in)
 Improved Thermal Performance:
23A at 70ºC at 1m/s (200LFM) for 3.3Vo
 High power density: 100W/in
3
 Low output ripple and noise
 Low output voltages down to 1V: Supports migration
to future IC and microprocessor supply voltages
 2:1 input voltage
 Remote Sense
 Remote On/Off
 Constant switching frequency
 Output overvoltage and Overcurrent protection
 Overtemperature protection
 Adjustable output voltage (+10% / -20%)
 Meets the voltage isolation requirements for
ETSI 300-132-2 and complies with and is licensed
for Basic Insulation rating per EN60950-1
 UL** 60950-1 Recognised, CSA
†
C22.2 No. 60950-
1-03 Certified, and VDE
‡
0805 (IEC60950, 3
rd
Edition) Licensed
 CE mark meets 2006/95/EC directive §
 ISO* 9001 certified manufacturing facilities
Applications
 Enterprise Networks
 Wireless Networks
 Access and Optical Network Equipment
 Enterprise Networks
 Latest generation IC’s (DSP, FPGA, ASIC) and
Microprocessor-powered applications.
Options
 Positive Remote On/Off logic
 Case ground pin (-H Base plate version)
 Auto restart after fault shutdown
Description
The QRW-series dc-dc converters are a new generation of DC/DC power modules designed for optimum efficiency
and power density. The QRW series provide up to 40A output current in an industry standard quarter brick, which
makes it an ideal choice for small space, high current and low voltage applications. The converter uses synchronous
rectification technology and innovative packaging techniques to achieve ultra high efficiency reaching 91% at 3.3V
full load. Thanks to the ultra high efficiency of this converter, the power dissipation is such that for most applications
a heat sink is not required. In addition, the QRW-series supports future migration of semiconductor and
microprocessor supply voltages down to 1.0V.
RoHS Compliant
