Data Sheet
August 24, 2010
QRW010/025/035/040 Series Power Modules; dc-dc Converters
36 Vdc - 75 Vdc Input, 1.0 to 12 Vdc Output; 10 A to 40 A
Lineage Power 36
Ordering Information
Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 1. Product Codes
Input Voltage
Output
Voltage
Output
Current
Efficiency Connector Type Product Codes Comcodes
48V (36-75Vdc) 12V 10A 91% Through hole QRW010A0B1 108967167
48V (36-75Vdc) 12V 10A 91% Through hole QRW010A0B41 108983032
48V (36-75Vdc) 12V 10A 91% Through hole QRW010A0B1Z CC109102992
48V (36-75Vdc) 12V 10A 91% Through hole QRW010A0B41-HZ CC109143228
48V (36-75Vdc) 5.0V 25A 92% Through hole QRW025A0A1 108965500
48V (36-75Vdc) 5.0V 25A 92% Through hole QRW025A0A41 108969288
48V (36-75Vdc) 5.0V 25A 92% Through hole QRW025A0A1Z CC109101474
48V (36-75Vdc) 5.0V 25A 92% Through hole QRW025A0A6Z CC109142675
48V (36-75Vdc) 5.0V 25A 92% Through hole QRW025A0A41Z CC109127214
48V (36-75Vdc) 5.0V 25A 92% Through hole QRW025A0A641Z CC109143211
48V (36-75Vdc) 5.0V 25A 92% Through hole QRW025A0A41-H 108982810
48V (36-75Vdc) 5.0V 25A 92% Through hole QRW025A0A71-H 108987264
48V (36-75Vdc) 5.0V 25A 92% Through hole QRW025A0A1-HZ CC109120755
48V (36-75Vdc) 5.0V 25A 92% Through hole QRW025A0A741-HZ CC109114204
48V (36-75Vdc) 3.3V 35A 91% Through hole QRW035A0F1 108965518
48V (36-75Vdc) 3.3V 35A 91% Through hole QRW035A0F1Z 108995230
48V (36-75Vdc) 3.3V 35A 91% Through hole QRW035A0F1-H 108967720
48V (36-75Vdc) 3.3V 35A 91% Through hole QRW035A0F1-HZ CC109144440
48V (36-75Vdc) 3.3V 35A 91% Through hole QRW035A0F61 108975491
48V (36-75Vdc) 3.3V 35A 91% Through hole QRW035A0F41Z CC109107612
48V (36-75Vdc) 3.3V 35A 91% Through hole QRW035A0F641Z CC109138970
48V (36-75Vdc) 3.3V 35A 91% Through hole QRW035A0F841-H 108981283
48V (36-75Vdc) 3.3V 35A 91% Through hole QRW035A0F741-HZ CC109114212
48V (36-75Vdc) 2.5V 35A 90% Through hole QRW035A0G1 108965526
48V (36-75Vdc) 2.5V 35A 90% Through hole QRW035A0G1-H 108968546
48V (36-75Vdc) 1.8V 40A 87% Through hole QRW040A0Y41 108969247
48V (36-75Vdc) 1.5V 40A 86% Through hole QRW040A0M1 108965534
