Data Sheet
August 24, 2010 36 Vdc - 75 Vdc Input, 1.0 to 12 Vdc Output; 10 A to 40 A
QRW010/025/035/040 Series Power Modules; dc-dc Converters
Absolute Maximum Ratings
Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. These are absolute stress
ratings only, functional operation of the device is not implied at these or any other conditions in excess of those given in the
operations sections of the data sheet. Exposure to absolute maximum ratings for extended periods can adversely affect the
device reliabiltiy.
Electrical Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature conditions.
CAUTION: This power module is not internally fused. An input line fuse must always be used.
This power module can be used in a wide variety of applications, ranging from simple stand-alone operation to an integrated
part of a sophisticated power architecture. To preserve maximum flexibility, internal fusing is not included; however, to achieve
maximum safety and system protection, always use an input line fuse. The safety agencies require a normal-blow fuse with a
maximum rating of 10 A (see Safety Considerations section). Based on the information provided in this data sheet on inrush
energy and maximum dc input current, the same type of fuse with a lower rating can be used. Refer to the fuse manufacturer’s
data for further information.
Parameter Device Symbol Min Max Unit
Input Voltage:Continuous
Transient (100ms)
All VI
VI, trans
—
—
80
100
Vdc
Vdc
Operating Ambient Temperature
(See Thermal Considerations section)
All TA –40 85 °C
Storage Temperature All Tstg –55 125 °C
I/O Isolation Voltage (100% factory Hi-Pot tested)
When using optional case ground pin
(option 7)
— — 1500
700
Vdc
Vdc
Parameter Device Symbol Min Typ Max Unit
Operating Input Voltage All VIN 36 48 75 Vdc
Maximum Input Current
(VI = 0 V to 75 V; IO = IO, max)
All — — 4.5 Adc
Inrush Transient All I 2 t 1 A 2 s
Input Reflected Ripple Current, peak-peak
(5 Hz to 20 MHz, 12 µH source impedance
See Test configuration section)
All 16 mAp-p
Input Ripple Rejection (120 Hz) All 60 dB
