GE Preliminary Data Sheet
CAR2512TE Front-End
Input: 90V
AC
to 264V
AC
; Output: 12 V
DC
@ 2500W; 3.3/5V
DC
standby @ 15W
February 7, 2014 ©2013 General Electric Company. All rights reserved. Page 5
Feature Specifications (continued)
Parameter Symbol Min Typ Max Unit
SMBAlert# (Interrupt) (pulled up internally via 10kΩ to 3.3V)
i t )
Logic High (No Alert - normal) V
OH
2.1  3.5 V
DC
Logic Low (Alert is set) I
OL
  20 mA
V
OL
0  0.4 V
DC
Current monitor (Imon) Resolution 15 mV/A
Measurement range I
OUT
0 208 A
DC
Measurement accuracy, load > 25% of FL, V
O
= 12V
DC
-5 +5 % of FL
Analog output range V
mon
0 3.3 V
DC
Sourced output current I
OUT
5 mA
DC
Digital Interface Specifications
Parameter Conditions Symbol Min Typ Max Unit
PMBus Signal Interface Characteristics
Input Logic High Voltage (CLK, DATA)
V IH 2.1 3.6 V
Input Logic Low Voltage (CLK, DATA) V IL 0 0.8 V
Input high sourced current (CLK, DATA) I
IH
0 10 μA
Output Low sink Voltage (CLK, DATA, SMBALERT#) I
OUT
=3.5mA V OL 0.4 V
Output Low sink current (CLK, DATA, SMBALERT#) I OL 3.5 mA
Output High open drain leakage current (CLK,DATA,
SMBALERT#)
V
OUT
=3.6V I
OH
0 10 μA
PMBus Operating frequency range Slave Mode F PMB 10 400 kHz
Digital Interface Specifications (continued)
Parameter Type Symbol Min Typ Max Unit
Measurement System Characteristics
Clock stretching t STRETCH 25 ms
I
OUT
measurement range Linear I
RNG
0 210 A
I
OUT
measurement accuracy 25°C I
ACC
-5 +5 %
V
OUT
measurement range Linear V
OUT(rng)
0 14 V
DC
V
OUT
measurement accuracy V
OUT(acc)
-5 +5 %
Temp measurement range Linear Temp (rng)
0 120 C
Temp measurement accuracy 4 Temp
(acc)
-5 +5 %
I
IN
measurement range Linear I
IN(rng)
0 40 A
AC
I
IN
measurement accuracy I
IN(acc)
-5 +5 %
V
IN
measurement range Linear V
IN(rng)
0 300 V
AC
V
IN
measurement accuracy V
IN(acc)
-5 +5 %
P
IN
measurement range Linear P
N(rng)
0 3000 W
P
IN
measurement accuracy P
IN(acc)
-5 +5 %
Fan Speed measurement range Linear 0 30k RPM
Fan Speed measurement accuracy -10 10 %
Fan speed control range Linear 0 100 %
4 Temperature accuracy reduces non-linearly with decreasing temperature
