GE Preliminary Data Sheet
CAR2512TE Front-End
Input: 90V
AC
to 264V
AC
; Output: 12 V
DC
@ 2500W; 3.3/5V
DC
standby @ 15W
February 7, 2014 ©2013 General Electric Company. All rights reserved. Page 4
Feature Specifications (continued)
Parameter Symbol Min Typ Max Unit
Output Voltage programming (Vprog)
Equation: Vout = 10.8 + (Vprog * 0.96)
Vprog range V
PROG
0  2.5 V
DC
Programmed output voltage range V
OUT
10.8  13.2 V
DC
Voltage adjustment resolution (8-bit A/D) V
OUT
 10  mV
DC
Output configured to 13.2V
DC
V
PROG
2.5 3.0 V
DC
Output configured to the 12V
DC
set-point V
PROG
3.0   V
DC
Interlock [short pin controlling presence of the 12V
DC
output]
12V output OFF V
I
2.5  5 V
DC
12V output ON V
I
0  0.8 V
DC
INPUT(AC)_OK (pulled up internally via 10kΩ to 3.3V)
Logic High (Input within normal range; V
IN
≥ 80V
AC
) I
OH
 20 µA
V
OH
2.1  3.5 V
DC
Logic Low (Input out of range; V
IN
≤ 75V
AC
) I
OL
  20 mA
V
OL
0  0.4 V
DC
DC_OK (pulled up internally via 10kΩ to 3.3V)
Logic High (Output voltage is present; V
OUT
≥ 10.7V
DC
) I
OH
 20 µA
V
OH
2.1  3.5 V
DC
Logic Low (Output voltage is not present; V
OUT
≤ 10.2V
DC
, and I
OL
  20 mA
Early_warning if output is about to go out of regulation) V
OL
0  0.4 V
DC
Over_Temperature_Warning# (pulled internally via 10kΩ to 3.3V)
Logic High (temperature within normal range) I
OH
 20 µA
V
OH
2.1  3.5 V
DC
Logic Low (temperature is too high) I
OL
  20 mA
V
OL
0  0.4 V
DC
Delayed shutdown after Logic Low transition Tdelay 10 sec
Fault# (pulled up internally via 10kΩ to 3.3V)
Logic High (No fault is present) I
OH
 20 µA
V
OH
2.1  3.5 V
DC
Logic Low (Fault is present) I
OL
  20 mA
V
OL
0  0.4 V
DC
PS_Present#
Logic High (Power supply is not plugged in)
Logic Low (Power supply is present) V
IL
0  0.4 V
DC
