9-36V ProLynx TM 5A: Non-Isolated DC-DC Power Modules
9Vdc –36Vdc input; 3Vdc to 18Vdc output; 5A to 2.5A Scaled output current
9Vdc –24Vdc input; -3.3Vdc to -18Vdc output; 5A to 0.7A Scaled output current
July 23, 2013 ©2012 General Electric Company. All rights reserved. Page 2
Absolute Maximum Ratings
Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. These are absolute stress ratings
only, functional operation of the device is not implied at these or any other conditions in excess of those given in the operations
sections of the data sheet. Exposure to absolute maximum ratings for extended periods can adversely affect the device reliability.
Parameter Device Symbol Min Max Unit
Input Voltage All V
IN
-0.3 37 V
Continuous
Operating Ambient Temperature All T
A
-40 85 °C
(see Thermal Considerations section) -D version T
A
-40 105 °C
Storage Temperature All T
stg
-55 125 °C
Electrical Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature conditions.
Parameter Device Symbol Min Typ Max Unit
Operating Input Voltage All V
IN
9 ⎯ 36 Vdc
Maximum Input Current All I
IN,max
5 Adc
(V
IN
=9V to 36V, I
O
=I
O, max
)
Input No Load Current
(V
IN
= 28V, I
O
= 0, module enabled) V
O,set
= 3Vdc I
IN,No load
26 mA
(V
IN
= 28V, I
O
= 0, module enabled) V
O,set
= 18Vdc I
IN,No load
50 mA
Input Stand-by Current All I
IN,stand-by
3 mA
(V
IN
= 28Vdc, module disabled)
Inrush Transient All I 2 t 0.5 A 2 s
Input Reflected Ripple Current, peak-to-peak
(5Hz to 20MHz, 1μH source impedance; V
IN
=0 to 36V
,
I
O
=
I
Omax
; See Test Configurations)
All 95 mAp-p
Input Ripple Rejection (120Hz) All -24 -45 -60 dB
CAUTION: This power module is not internally fused. An input line fuse must always be used.
This power module can be used in a wide variety of applications, ranging from simple standalone operation to an integrated part
of sophisticated power architecture. To preserve maximum flexibility, internal fusing is not included; however, to achieve maximum
safety and system protection, always use an input line fuse. The safety agencies require a fast-acting fuse with a maximum rating
of 8 A (see Safety Considerations section). Based on the information provided in this data sheet on inrush energy and maximum dc
input current, the same type of fuse with a lower rating can be used. Refer to the fuse manufacturer’s data sheet for further
information.
