O-02 Control Word Source

Option:

Function:

Select the source of the control word: one of two serial interfaces or four installed options. During initial
power-up, the drive automatically sets this parameter to Option A [3] if it detects a valid network option
installed in slot A. If the option is removed, the drive detects a change in the configuration, sets par.
O-02 Control Word Source back to default setting Drive Port, and the drive then trips. If an option is installed
after initial power-up, the setting of par. O-02 Control Word Source will not change but the drive will trip
and display: Alarm 67 Option Changed.

[0]

None

[1]

Drive Port

[2]

USB Port

[3] *

Option A

[4]

Option B

[5]

Option C0

[6]

Option C1

[30]

External Can

NB!
This parameter cannot be adjusted while the motor is running.

O-03 Control Word Timeout Time

Range:

Function:

60.0 s*

[1.0 - 18000.0 s]

Enter the maximum time expected to pass between the reception of two consecutive messages. If this
time is exceeded, it indicates that the serial communication has stopped. The function selected in par.
O-04 Control Word Timeout Function Control Time-out Function will then be carried out.

In LonWorks the following variables will trigger the Control Word Time parameter:

nviStartStop

nviReset Fault

nviControlWord

nviDrvSpeedStpt

nviRefPcnt

nviRefHz

O-04 Control Word Timeout Function

Option:

Function:

Select the time-out function. The time-out function is activated when the control word fails to be updated
within the time period specified in par. O-03 Control Word Timeout Time. Choice [20] only appears after
setting the N2 protocol.

[0] *

Off

[1]

Freeze output

[2]

Stop

[3]

Jogging

[4]

Max. speed

[5]

Stop and trip

[7]

Select setup 1

[8]

Select setup 2

[9]

Select setup 3

[10]

Select setup 4

[20]

N2 Override Release
