4 How to Configure the System
4.1 Configuring BACnet
4.1.1 Initialization Procedure
The Initialization Procedure is explained by the flow chart given below:
Initialization Parameter
General Settings
Name Parameter Number Default Value Setting for BACnet
Control Site O-01 Digital and control word Digital and control word
Control word source O-02 Drive RS-485 Drive RS-485
ControlWord Timeout time O-03 1.0 sec 1.0 sec
ControlWord Timeout Function O-04 Off Off
End of Timeout Function O-05 Resume setup Resume setup
Reset ControlWord Timeout O-06 Do not reset Do not reset
Diagnosis O-07 Set up Don’t care
ControlWord Profile O-10 Drive protocol Drive protocol
Drive Port Settings
Name Parameter Number Default Value Setting for BACnet
Protocol O-30 Drive Drive Option
Address O-31 1 1
Baud Rate O-32 9600 baud 9600 baud
Minimum Response Delay O-35 10 ms 10 ms
Max Response Delay O-36 5000 ms 5000 ms
Table 4.1: 1) Please see also section: Parameter Overview >Parameter List.
