Af-600fp bacnet – GE Industrial Solutions AF-600 FP BACnet User Manual
Page 18

•
MS/TP running at 38.400 Baud
•
MAC address 20 for the AF-600 FP
•
BACnet Device Instance 0 1025
•
Highest number of a Master stack is 35
•
Start/stop of Drive from BACnet only
•
Reference from BACnet
•
Read status of Drive (Actual speed)
Set the following parameters:
Name
Parameter number
Value
Protocol
O-30
Drive option [9]
Address
O-31
20
Drive Port Baud Rate
O-32
38,400 Baud [4]
Coasting Select
O-50
Bus [1]
BACnet device Instance
BN-70
1025
MS/TP Max Masters
BN-72
35
After the parameters have been set according the table above, the drive has to be unpowered and repowered before the changes take effect. When the drive is
detected by the BMS, the drive can be controlled by BV:1, which will start the motor if set to [1]. Setting AV:0 will set the speed reference of the drive. The actual
speed can be monitored via AV:1. See also Analog Input- and Output Objects section.
AF-600FP BACnet
17
