ASTAT-XT RVSS PANEL
INSTALLATION Determine conduit entry and exit locations on the enclosure before mounting.
See the appropriate Outline drawing for recommended conduit locations.
Allow for input and output power wiring to be located in separate conduit.
No conduit holes are provided in the enclosure except knockouts for Type-1
Enclosures; therefore the customer must install all conduit holes. Place a
protective covering over the components of the panel while installing the
conduit holes to prevent metal shavings or chips from landing on part or
electronic boards.
For NEMA 12 and 3R enclosure types, liquid tight conduit (UL listed rain tight
conduit hubs) and fittings must be installed to maintain the enclosure
integrity.
GROUNDING
All panels/enclosures must be grounded.
Each panel contains a grounding lug with provisions for connecting a field-
grounding conductor.
All field wiring shall be copper and have a minimum insulation rating of 75

C
(167

F).
Size grounding conductors according to local and national codes.
Grounding methods must comply to local and national codes.
POWER WIRE
(Greater than 120 VAC)
All field wiring shall be copper and have a minimum insulation rating of 75

C
(167

F).
Size all wire based on panel nameplate current ratings in accordance with
local and national codes. Does not use the cable sizes list ED230209 in
manuals.
All power wiring must be routed away from other wiring. Avoid running power
wiring parallel to other wiring without a minimum separation distance of four
(4) inches. Power wiring should only cross perpendicular to other wiring.
Input and output power shall be connected as per the wiring diagram.
CAUTION: Failure to cover components from metal shavings may result
in damage to equipment.
