GE Industrial Solutions ASTAT-XT RVSS PANEL - Manual (Page 27)

DEH40624 - Page 4 AN BL-0350, Rev.01, 08/20/2010
ASTAT-XT RVSS PANEL
Table C
RVSS Panels – 575 VAC
Current Ratings and Maximum Fuse Sizes
RVSS Panel RVSS Panel RVSS Panel Max Allowable
HP Rating Duty Rating Current Rating Fuse Size
5 Light Duty NEMA 10 9.1 10
15 Light Duty NEMA 10 20 30
30 Light Duty NEMA 10 35 60
50 Light Duty NEMA 10 56 80
60 Light Duty NEMA 10 66 100
100 Light Duty NEMA 10 103 175
125 Light Duty NEMA 10 129 200
150 Light Duty NEMA 10 148 250
250 Light Duty NEMA 10 246 400
400 Light Duty NEMA 10 386 600
500 Light Duty NEMA 10 478 800
5 Normal Duty NEMA 20 9.1 10
15 Normal Duty NEMA 20 20 30
25 Normal Duty NEMA 20 30 50
40 Normal Duty NEMA 20 45 60
50 Normal Duty NEMA 20 56 80
60 Normal Duty NEMA 20 66 100
75 Normal Duty NEMA 20 81 125
100 Normal Duty NEMA 20 103 175
150 Normal Duty NEMA 20 148 250
200 Normal Duty NEMA 20 196 350
300 Normal Duty NEMA 20 293 500
400 Normal Duty NEMA 20 386 600
500 Normal Duty NEMA 20 478 800
5 Heavy Duty NEMA 30 9.1 10
10 Heavy Duty NEMA 30 14 20
25 Heavy Duty NEMA 30 30 50
40 Heavy Duty NEMA 30 45 60
50 Heavy Duty NEMA 30 56 80
60 Heavy Duty NEMA 30 66 100
75 Heavy Duty NEMA 30 81 125
100 Heavy Duty NEMA 30 103 175
125 Heavy Duty NEMA 30 129 200
200 Heavy Duty NEMA 30 196 350
300 Heavy Duty NEMA 30 293 500
400 Heavy Duty NEMA 30 388 600
500 Heavy Duty NEMA 30 478 800
27
