DEH40626 - Page 1 AN BL-0350, Rev.01, 08/20/2010
ASTAT-XT RVSS PANEL
In-Warranty Information Form
The purpose of this form is to provide specific information to RVSS Panels to aid in
expediting part replacement and/or troubleshooting assistance for RVSS Bypass OR NON
Bypass panels. The following information is required prior to any assistance being provided.
Unit Model Number:
Unit Serial Number:
Start-Up Date:
Failure Date:
I. Application Information:
Input Transformer: _____ kVA
wiring distance between motor & ASTAT ______ ft.
Power Factor Correction Capacitors: _____ Yes ( _______ Microfarad)
_____ No
Other Equipment on Same Power: _____ Yes _____ No
If Yes, what? ______________________________________________________
II. Function Code Different From Factory Settings:
FC Setting FC Setting
III. Failure Message:
Latest Fault Previous Fault
IV. Status When Failure Occurred (check one):
_____ Power Up
_____ Running _____ Starter Mode _____ Bypass Mode
V. Description Of Failure:
______________________________________________________________________________
______________________________________________________________________________
Once all the required information above is acquired, contact the following number for
assistance:
GE Industrial Solutions
Phone:
1-800-533-5885
(24hrs.)
