DEH40623 - Page 6 AN BL-0464, Rev.02, 04/15/2012
ASTAT-XT RVSS PANEL
Table C
RVSS Panels – 575 VAC
Wire Sizes and Torque Requirements
Device
RVSS Panel Hp
Rating(s)
Minimum Wire
Size
Maximum Wire
Size Required Torque
NON FUSED DISCONNECTOR 5 - 15Hp # 14 (1) AWG # 10 AWG 27 lb.in.
25 - 40Hp # 10 (1) AWG # 3 AWG 58 lb.in.
50 -60Hp # 10 (1) AWG # 3 AWG 58 lb.in.
75 - 125Hp # 6 (1) AWG # 3/0 AWG 200 lb.in.
150 - 250Hp #2 (1) AWG 600 MCM 500 lb.in.
300Hp #2 (2) AWG 600 MCM 500 lb.in.
400 - 500Hp #2 (2) AWG 600 MCM 500 lb.in.
FUSED DISCONNECTOR 5 - 15Hp # 10 (1) AWG # 3 AWG 58 lb.in.
25 - 40Hp # 10 (1) AWG # 3 AWG 58 lb.in.
50 - 60Hp # 14 (1) AWG # 2/0 AWG 120 lb.in.
75 - 125Hp # 6 (1) AWG # 3/0 AWG 200 lb.in.
150 - 250Hp #2 (1) AWG 600 MCM 500 lb.in.
300 - 400Hp #2 AWG 600 MCM 500 lb.in.
500Hp #2 (2) AWG 600 MCM 500 lb.in.
Circuit Breaker 5 - 75Hp # 12 AWG # 3/0 AWG 160 lb.in.
100 - 150Hp # 8 AWG 350 MCM 275 lb.in.
200 - 400Hp # 8 AWG 400 MCM 275 lb.in.
500Hp 250 MCM 500 MCM 375 lb.in.
Contactors 5 - 25Hp # 14 AWG # 10 AWG 16 lb. in.
30 - 60Hp # 14 AWG # 10 AWG 40 lb. in.
75Hp # 10 AWG # 2/0 AWG 60 lb. in.
100 - 125Hp # 6 AWG 250 MCM 275 lb. in.
150 - 300Hp # 6 AWG 350 MCM 200 lb. in.
400 - 500Hp # 8 AWG 500 MCM 375 lb. in.
Overload Relay 5 - 25Hp # 14 AWG # 8 AWG 24 lb. in.
30 - 75Hp # 10 AWG # 3 AWG 50 lb. in.
100 - 125Hp # 6 AWG 250 MCM 275 lb. in., Note 2
150 - 300Hp # 6 AWG 350 MCM 200 lb. in., Note 2
400 - 500Hp # 8 AWG 500 MCM 375 lb. in., Note 2
Continued…
