DEH40624 - Page 2 AN BL-0350, Rev.01, 08/20/2010
ASTAT-XT RVSS PANEL
Table A
RVSS Panels – 230 VAC
Current Ratings and Maximum Fuse Sizes
RVSS Panel RVSS Panel RVSS Panel Max Allowable
HP Rating Duty Rating Current Rating Fuse Size
2 Light Duty NEMA 10 13.8 12
5 Light Duty NEMA 10 22.2 30
10 Light Duty NEMA 10 35 50
20 Light Duty NEMA 10 57 90
25 Light Duty NEMA 10 71 100
40 Light Duty NEMA 10 107 175
50 Light Duty NEMA 10 133 200
60 Light Duty NEMA 10 157 200
100 Light Duty NEMA 10 251 400
150 Light Duty NEMA 10 363 600
200 Light Duty NEMA 10 485 800
250 Light Duty NEMA 10 609 800
2 Normal Duty NEMA 20 13.8 12
5 Normal Duty NEMA 20 22.2 30
10 Normal Duty NEMA 20 35 50
15 Normal Duty NEMA 20 45 60
20 Normal Duty NEMA 20 57 90
25 Normal Duty NEMA 20 71 100
30 Normal Duty NEMA 20 83 125
40 Normal Duty NEMA 20 107 175
50 Normal Duty NEMA 20 133 200
60 Normal Duty NEMA 20 157 200
75 Normal Duty NEMA 20 195 350
100 Normal Duty NEMA 20 251 400
150 Normal Duty NEMA 20 363 600
200 Normal Duty NEMA 20 485 800
250 Normal Duty NEMA 20 609 800
2 Heavy Duty NEMA 30 13.8 12
3 Heavy Duty NEMA 30 16.6 17.5
10 Heavy Duty NEMA 30 35 50
15 Heavy Duty NEMA 30 45 60
20 Heavy Duty NEMA 30 57 90
30 Heavy Duty NEMA 30 83 125
40 Heavy Duty NEMA 30 107 175
50 Heavy Duty NEMA 30 133 200
75 Heavy Duty NEMA 30 195 350
100 Heavy Duty NEMA 30 251 400
150 Heavy Duty NEMA 30 363 600
200 Heavy Duty NEMA 30 485 800
250 Heavy Duty NEMA 30 609 800
25
