DEH40623 - Page 2 AN BL-0464, Rev.02, 04/15/2012
ASTAT-XT RVSS PANEL
Table A
RVSS Panels – 230 VAC
Wire Sizes and Torque Requirements
Device
RVSS panel Hp
Rating(s) Minimum Wire Size
Maximum Wire
Size Required Torque
NON FUSED
DISCONNECTOR
2 - 5Hp
# 14 (1) AWG # 10 AWG 27 lb.in.
10 - 15Hp # 10 (1) AWG # 3 AWG 58 lb.in.
20 - 25Hp # 10 (1) AWG # 3 AWG 58 lb.in.
30 - 60Hp # 6 (1) AWG # 3/0 AWG 200 lb.in.
75 - 100Hp #2 (1) AWG 600 MCM 500 lb.in.
150Hp #2 (2) AWG 600 MCM 500 lb.in.
200Hp #2 (2) AWG 600 MCM 500 lb.in.
FUSED DISCONNECTOR 2 - 5Hp # 10 (1) AWG # 3 AWG 58 lb.in.
10 - 15Hp # 10 (1) AWG # 3 AWG 58 lb.in.
20 - 25Hp # 14 (1) AWG # 2/0 AWG 120 lb.in.
30 - 60Hp # 6 (1) AWG # 3/0 AWG 200 lb.in.
75 - 100Hp #2 (1) AWG 600 MCM 500 lb.in.
150Hp #2 AWG 600 MCM 500 lb.in.
200Hp #2 (2) AWG 600 MCM 500 lb.in.
250Hp #2 (2) AWG 600 MCM 500 lb.in.
Circuit Breaker 2 - 30Hp # 12 AWG # 3/0 AWG 160 lb.in.
40 - 60Hp # 8 AWG 350 MCM 275 lb.in.
75 - 150Hp # 8 AWG 400 MCM 275 lb.in.
200 - 250Hp 250 MCM 500 MCM 375 lb.in.
Contactors 2 - 10Hp # 14 AWG # 10 AWG 16 lb. in.
15 - 25Hp # 14 AWG # 10 AWG 40 lb. in.
30 - 40Hp # 10 AWG # 2/0 AWG 60 lb. in.
50 - 60Hp # 6 AWG 250 MCM 275 lb. in.
75 - 100Hp # 6 AWG 350 MCM 200 lb. in.
150 - 250Hp # 8 AWG 500 MCM 375 lb. in.
Overload Relay 2 - 10Hp # 14 AWG # 8 AWG 24 lb. in.
15 - 40Hp # 10 AWG # 3 AWG 50 lb. in.
50 - 60Hp # 6 AWG 250 MCM 275 lb. in., Note 2
75 - 100Hp # 6 AWG 350 MCM 200 lb. in., Note 2
150 - 250Hp # 8 AWG 500 MCM 375 lb. in., Note 2
Continued…
33
