DEH40623 - Page 11 AN BL-0464, Rev.02, 04/15/2012
ASTAT-XT RVSS PANEL
Table E
RVSS Panels
Non-Bypass Configuration
HP Ratings
Estimated Watt Loss
(Watts) at
230V 460V 575V
2 121 - -
3 160 - -
5 163 121 121
7.5 - 160 -
10 225 163 160
15 367 - 163
20 391 225 -
25 460 246 225
30 632 367 229
40 802 391 367
50 804 460 391
60 991 632 460
75 1538 751 632
100 2119 804 804
125 - 991 804
150 2136 1461 846
200 3155 1583 1583
250 4301 2119 1583
300 - 2136 2119
350 - 2572 -
400 - 3155 2572
500 - 4301 4207
42
