GE Industrial Solutions ASTAT-XT RVSS PANEL - Manual (Page 35)

DEH40623 - Page 4 AN BL-0464, Rev.02, 04/15/2012
ASTAT-XT RVSS PANEL
Table B
RVSS Panels – 460 VAC
Wire Sizes and Torque Requirements
Device
RVSS Panel Hp
Rating(s) Minimum Wire Size
Maximum Wire
Size Required Torque
NON FUSED
DISCONNECTOR
5 - 10Hp
# 14 (1) AWG # 10 AWG 27 lb.in.
20 - 30Hp # 10 (1) AWG # 3 AWG 58 lb.in.
40 - 50Hp # 10 (1) AWG # 3 AWG 58 lb.in.
60 - 100Hp # 6 (1) AWG # 3/0 AWG 200 lb.in.
125 - 200Hp #2 (1) AWG 600 MCM 500 lb.in.
250 - 350Hp #2 (2) AWG 600 MCM 500 lb.in.
400 - 500Hp #2 (2) AWG 600 MCM 500 lb.in.
FUSED DISCONNECTOR 5 - 10Hp # 10 (1) AWG # 3 AWG 58 lb.in.
20 - 30Hp # 10 (1) AWG # 3 AWG 58 lb.in.
40 - 50Hp # 14 (1) AWG # 2/0 AWG 120 lb.in.
60 - 100Hp # 6 (1) AWG # 3/0 AWG 200 lb.in.
125 - 200Hp #2 (1) AWG 600 MCM 500 lb.in.
250 - 350Hp #2 AWG 600 MCM 500 lb.in.
400 - 500Hp #2 (2) AWG 600 MCM 500 lb.in.
Circuit Breaker 5 - 75Hp # 12 AWG # 3/0 AWG 160 lb.in.
100 - 150Hp # 8 AWG 350 MCM 275 lb.in.
200 - 350Hp # 8 AWG 400 MCM 275 lb.in.
400 - 500Hp 250 MCM 500 MCM 375 lb.in.
Contactors 5 - 25Hp # 14 AWG # 10 AWG 16 lb. in.
30 - 50Hp # 14 AWG # 10 AWG 40 lb. in.
60 - 75Hp # 10 AWG # 2/0 AWG 60 lb. in.
100 - 125Hp # 6 AWG 250 MCM 275 lb. in.
150 - 250Hp # 6 AWG 350 MCM 200 lb. in.
300 - 500Hp # 8 AWG 500 MCM 375 lb. in.
Overload Relay 5 - 25Hp # 14 AWG # 8 AWG 24 lb. in.
30 - 75Hp # 10 AWG # 3 AWG 50 lb. in.
100 - 125Hp # 6 AWG 250 MCM 275 lb. in., Note 2
150 - 250Hp # 6 AWG 350 MCM 200 lb. in., Note 2
300 - 500Hp # 8 AWG 500 MCM 375 lb. in., Note 2
Continued…
