CPS2500D +/-190V Downstream System
Issue 4 January 2008 Electrical Interface Reference Information 6 - 3
P321
P321
Pin Function
1 Power Major Alarm NC
2 Power Major Alarm Common
3 Power Major Alarm NO
4 Power Minor Alarm NC
5 Power Minor Alarm Common
6 Power Minor Alarm NO
7-16 No Connection
Notes:Both alarms are fail-safe isolated Form C contact closures
NC = Normally Closed, NO = Normally Open
Use same ratings for relays as CPS4000 alarm relays
Alternate Alarm Wireset
Alarm Output Connector
Pin Function
1 Power Major Alarm NC
2 Power Major Alarm Common
3 Power Major Alarm NO
4 Power Minor Alarm NC
5 Power Minor Alarm Common
6 Power Minor Alarm NO
Notes:Both alarms are fail-safe isolated Form C contact closures
NC = Normally Closed, NO = Normally Open
Use same ratings for relays as CPS4000 alarm relays
To create a custom wireset that connects directly to the shelf, mate for the
Alarm Output Connector can be constructed using:
• AMP 6 Position Housing 1445022-6
• AMP Socket Contact 794606-1
• 22 AWG Stranded Wire
