Page 43: 6 electrical interface reference information, 6electrical interface reference information
CPS2500D +/-190V Downstream System
Issue 4 January 2008
Electrical Interface Reference Information 6 - 1
6
Electrical Interface Reference
Information
Shelf Electrical
Interfaces
Interface
Cable Length
(inches)
Connector
Label
Comments
+/- 190V DC Input
12
P800
-48V DC Output
24
P700
Use 8 AWG stranded THHN wire.
Alarm Output
24
P321
Connector Details
The following parts are used on QS800A wiresets. Choose the appropriate
mating connector for your specific application.
Connector
Description
Manufacturer Part Number
P800
50-position plug assembly (1/26 side entry) Cinch KS21997L1
P700
3-position receptacle
Molex Receptacle 42816-0312
with 42815-0031 (8 AWG wire)
P321
16-position receptacle
Molex Receptacle 39-01-2165
with 39-00-0059 sockets (24-18
AWG wire)
