CPS2500D +/-190V Downstream System
6 - 2 Electrical Interface Reference Information Issue 4 January 2008
Connector Pinouts P800
P800
-190V Pin +190V Pin Pair
1 26 1
2 27 2
3 28 3
4 29 4
5 30 5
6 31 6
7 32 7
8 33 8
9 34 9
10 35 10
11 36 11
12 37 12
13 38 13
14 39 14
15 40 15
16 41 16
17 42 17
18 43 18
19 44 19
20 45 20
Pins 20-25 and 46-50 are not connected.
Mate for P800 can be constructed using AMP Kit part number 1-229913-1.
This 50 pin “Cable to Cable Receptacle with Tapered Cover and Screw Kit”
accepts 24 AWG solid or stranded wire. The cable housing should be dressed
away from pins 1 and 26 with the bundle exiting over pins 25 and 50.
P700
P700
Pin With jumper in place (default) With jumper removed
1 Not Used No Connection
2 -48V -48V
3 RTN / Frame Ground RTN
To create a custom wireset that connects directly to the shelf, mate for P700
can be constructed using:
• Molex Mini-Fit SR. 3 position housing: 42816-0312
• Molex Mini-Fit SR 8 AWG contact 42815-0031
• 8 AWG stranded UL1028 MTW 600V wire
Our stock cable uses black for -48 and white for return
