Manual Breaker Injection 47
1.9.2 Manual circuit breaker injection input range
Frequency Frequency of the Signal to be injected.
Breaker Connection Flow current Forward / Reverse connected circuit breakers.
Voltage Inputs Inputs for Voltage Phases.
Current Inputs Inputs for Current phases.
Test Settings for Fault Generation Display of Current and Voltage settings.
Test Results Once the test is performed, it displays the time stamping of circuit
breaker status and the device that actuated the circuit breaker (Flux
Shifter or Breaker Open).
Test Time Time entry for test kit execution.
Table 1-16 Setup
Table 1-17 Manual circuit breaker injection input range
Parameter Range
Voltage 0 to 2x PT Rating Volts
Current 0 to 28x CT Rating Amps
Phase Angle –360° to +360°
Test Time 0.5 to 17000 secs
