8. Select the Ground Fault Defeat or Resume depending on the Fault Level test required.
9. Enter the Frequency of the test kit output.
10. Enter the Breaker connection Forward or Reverse direction.
11. Enter the desired Voltage and Phase angle for Voltage phases.
12. Enter the desired Current and Phase angle for Current phases.
13. Enter the Test time for the test signals to be injected.
14. Press Perform test to perform the test.
1.9.1 Setup
Table 1-16 Setup
Frame Rating Select Frame Rating.
CT Rating Select CT Rating.
Rating Switch Select Rating Switch.
PT Rating Select PT Rating.
Test Name Unique test identifier, assigned by the test kit, generated by the type of
test selected and the date the test is performed.
Test Description Lets the user enter the Test Description (150-character limitation)
Operator Let the user enter the operator name (20-character limitation)
Breaker Trip Specifies whether the test will physically trip the circuit breaker.
; – Circuit Breaker will Trip
† – Circuit Breaker will not Trip
Ground Fault Allows users to temporarily Defeat Ground Fault during the test, or to
Resume/Run Ground Fault as normal during the test. Ground Fault
must be defeated for single phase tests—otherwise a trip on Ground
Fault will occur.
; – GF will Resume/Run as Normal.
† – GF will be temporarily defeated during the test period.
Note: After the test has concluded, Ground Fault will resume
automatically.
This feature is enabled only when Ground Fault is enabled in the
selected circuit breaker.
Maximum Test Voltage Displays Maximum Test Voltage that can be set for testing from
Manual Injection.
Maximum Test Current Displays Maximum Test Current that can be set for testing from
Manual Injection.
