Appendix A

Specifications

Specification Value

Spectrometer range: 200-980 nm

Resolution:

0.1 nm (FWHM)

Detection:

CCDs with a combined 14,336 pixels

Frame rate:

10 Hz capability, computer-controlled

Integration time:

2.1 ms; variable in the free-run mode

Trigger delay:

-121

µs to +135 µs in 500 ns steps, computer-controlled

Trigger jitter:

+/-250 ns

Trigger level:

TTL not to exceed 5.5 V

Computer
connection:

USB 1.1 (in all computers)

Software: OOILIBS

Power requirement:

5 volts at <1 amp, power supply included

Input optical fiber:

2-meter, multimode sampling probe with SMA connector and collimating
lens

Size:

84HP x 3U Rack Housing with handles (130 mm x 483 mm x 350 mm)

Certification: CE

161-00000-000-02-0406
