2: Installing the LIBS System
OOILIBS Software
OOILIBS Software was designed specifically for the LIBS2000+ System. It records and stores data for
export to Microsoft Excel and similar programs using the standard Microsoft commands such as File
Save, File Print, etc.
Caution
You MUST install the OOILIBS software application prior to connecting the LIBS
System hardware to the PC. The OOILIBS software installation installs the drivers
required for HR2000 spectrometer installation. If you do not install OOILIBS first,
the system will not properly recognize the spectrometers.
If you have already connected the spectrometers to the PC prior to installing OOIBase32, consult Chapter
4:
Troubleshooting for information on correcting a corrupt HR2000 installation.
► Procedure
1. Insert the Software and Technical Resources CD that you received with your LIBS2000+ System
and download the OOILIBS software that you purchased to your PC. The password for this
software is on the back of the CD jacket.
2. Follow the prompts in the Installation Wizard to install the software.
Hardware Cabling
► Procedure
1. Plug the external +5 VDC power supply into the spectrometer rack.
Rear Panel of Spectrometer Rack
2. Plug the USB cable into the USB port on the rear of the spectrometer rack, then into the PC’s
USB port.
