4. Upgrading Firmware
44
4 4 . . U U p p g g r r a a d d i i n n g g t t h h e e F F i i r r m m w w a a r r e e
Occasionally, updated firmware may become available for your Modbus gateway. The
firmware can be upgraded using the Zlinx Manager software. The following procedure
describes the firmware updating process:
1. Click the Upgrade button to open the Firmware Upgrade dialog box.
Figure 49. Firmware Upgrade Dialog Box
The name of the currently selected Modbus gateway appears in the top drop down
list. Other Modbus gateways (that have already been discovered) can be selected from
the drop down list, if desired.
The current firmware version of the selected Modbus gateway is shown in the text
below the Modbus gateway name.
Information about the selected firmware file is shown in the third text box.
