Port VLAN Example scenario :
ports 1,2,3 - control system (only communicate with each other and the 2 PC's)
ports 4,5 - PCs (each communicate with all ports 1 thru 9)
ports 6,7,8,9 office system (only communicate with each other and the 2 PC's)
For example: TX 7 to 3 and no ports RX.
Notice below,, the configuration step:
“Would you like all these ports to have PVID=4 ?
Enter 'NO' or (YES):
CLI>no
Enter ports to have PVID=4
(Example: '3,6,12,14
Enter Port Numbers (or ESC to exit)> 4,5”
Continued on next sheet….
CLI\SWITCH\VLAN>port
Wait..........
Port VLAN selected.
CLI\SWITCH\VLAN>enable
Port VLAN is Enabled.
CLI\SWITCH\VLAN>group2
Configure Port VLAN Group 2.
Enter ports to Join VLAN Group 2
(Example: '3,6,12,14
Enter Port Numbers (or ESC to exit)> 1,2,3,4,5
These ports were removed from group1: 1 2 3 4 5
Would you like all these ports to have PVID=2 ?
Enter 'NO' or (YES):
CLI>
CLI\SWITCH\VLAN>group3
Configure Port VLAN Group 3.
Enter ports to Join VLAN Group 3
(Example: '3,6,12,14
Enter Port Numbers (or ESC to exit)> 4,5,6,7,8,9
These ports were removed from group1: 6 7 8 9
Would you like all these ports to have PVID=3 ?
Enter 'NO' or (YES):
CLI>
